The SPARK Flex is a new smart motor controller that is compatible with the REV ION System. Its dockable form factor allows for the direct mounting onto a NEO Vortex, simplifying wiring while maintaining flexibility. Improving upon the...

The Flex Dock transforms the SPARK Flex (REV-11-2159) into a standalone motor controller, supporting REV brushless motors and virtually any 12V brushed DC motor by providing standard phase wire outputs. The 6-pin JST PH encoder port is compatible with...

The MAXSpline Encoder delivers high accuracy and robust performance while integrating seamlessly with the MAXSpline ecosystem. Using the same proven magnetic sensing architecture as the Through Bore Encoder V2, this model adds expanded connectivity...

Building on the robust foundation of the original SPARK, the SPARK MAX Motor Controller incorporates advanced brushed and brushless DC motor control in a small and easy-to-use package with PWM, CAN, and USB connectivity. Never before has an FRC...

The REV USB PS4 Compatible Gamepad is compatible with both the REV DUO and REV ION Systems. Plug the REV Gamepad directly into a Driver Hub to enable feature rich control of your robot. Additionally, when plugged into a PC, it offers an Xbox...

The REV Power Distribution Hub (PDH) is the latest evolution in power distribution for the FIRST Robotics Competition (FRC).  With 20 high-current (40A max) channels, 3 low-current (15A max), and 1 switchable low-current channel, the PDH...

The REV Mini Power Module (MPM) is a compact power distribution module that allows you to securely and quickly power peripheral devices to your robot. Need more low-current channels on your PDH? Wire the MPM to one of the high-current channels on the PDH...

The REV Radio Power Module is designed to keep one of the most critical system components, the OpenMesh OM5P-AC WiFi radio, powered in the toughest moments of the competition. Traditional barrel jacks easily work themselves loose and often require hacks...

The REV Pneumatic Hub is a standalone module that is capable of switching both 12V and 24V pneumatic solenoid valves. The Pneumatic Hub features 16 solenoid channels which allow for up to 16 single-acting solenoids, 8 double-acting solenoids, or a...

The SPARK Flex Data Port Breakout Cable (REV-11-2853) breaks out the default pin functions of the SPARK Flex Data Port into commonly used connectors for external sensors. The keyed and locking Data Port connector ensures a secure and aligned fit when...

The USB-A to USB-C 2.0 Cable - 2m (REV-11-1232) is a longer version of the USB-A to USB-C cable included with the SPARK MAX Motor Controller and the Control Hub. Use this cable to connect your SPARK MAX or Control Hub to a standard computer from up to 2...

Connect the REV Through Bore Encoder directly to the SPARK MAX Data Port using the Absolute Encoder Adapter (REV-11-3326). This adapter connects the Absolute Duty Cycle output of the Through Bore Encoder to the correct SPARK MAX Data Port pins, leaving...

The 36in PWM Cable - 4 Pack (REV-11-1130-PK4) is an ideal servo extension, providing a 3ft reach for servos, sensors, and other PWM-controlled devices. Featuring a universal 3-pin design with a female connector on one end and a male connector on the...

2-pin header cable that can be used for connecting signals, sensors or any other spots on robots. Features 2 female 0.1in pitch connectors on each end.  Specifications Length: 91cm (36in) 2 pin receptacle on 0.1in pitch Wire Colors: red, black 22...

The Molex MicroFit+ Power and CAN Cable is the dedicated replacement and accessory cable for the MAXSpline Through Bore Encoder. It provides both power and CAN connectivity through a compact, secure 2x2 Molex MicroFit+ latching connector. While currently...

The Digital LED Indicator is a LED signal module that is digitally controlled (active low) and offers three colors: red, green, and amber. The Digital LED Indicator is designed to directly interface with the DIO ports of the Expansion Hub or Control Hub...

Touch sensor is best used for user input, but can also be used as a limit switch.  Configuration The REV Touch Sensor is a digital sensor that is wired to the N+1 channel on our standard 4-pin JST PH connector. In other words, the REV Expansion Hub...

The 36in CAN Extension Cable is a 3-pin connector to interface with existing CAN devices.  Specifications Length: 36in (3ft) Wire Colors: yellow, green 22 AWG

These JST PH 6-pin Joiner Boards are intended to be used with the JST PH 6-pin Extension Cables to extend the reach of your NEO Brushless Motor sensor cables.

This JST-PH 6-pin Breakout Board is designed to adapt external sensors to the SPARK MAX 6-pin Encoder Port standard. It features a JST PH 6-pin connector, labeled solder pads, and through-hole pads that are compatible with popular 63R style quadrature...
