Description
ION Compliant Wheels are compatible with the REV ION System and come in a wide range of sizes, durometers, and bores. Larger wheels contain the MAXSpline bore, but can be adapted to other bores with a separate MAXHub. The radial spoke profile allows for more consistent compliance, and more compression than other compliant wheels.
Specifications
- Compliant Wheel - 2in - MAXSpline
- Material: TPR
- Durometer: 30A (Medium - Dark Grey)
- Width: 11.1mm (0.44in)
- Weight: 13g (0.029lb)
- Compliant Wheel - 2in - 1/2in Hex
- Material: Glass-Filled Nylon & TPR
- Durometer: Varies (see table below)
- Width: 12.7mm (0.50in)
- Weight: 18g (0.039lb)
- Compliant Wheel - 3in - MAXSpline
- Material: Glass-Filled Nylon & TPR
- Durometer: Varies (see table below)
- Width: 25.4mm (1.00in)
- Weight: 84g (0.19lbs)
- Compliant Wheel - 4in - MAXSpline
- Material: Glass-Filled Nylon & TPR
- Durometer: Varies (see table below)
- Width: 25.4mm (1.00in)
- Weight: 128g (0.28lbs)
| HARDNESS | COLOR | DUROMETER |
| Soft like a rubber band | Light Gray | 30A |
| Medium like a pencil eraser | Dark Gray | 40A |
| Hard like a tire tread | Black | 60A |
Documentation
- ION Build System Guide
- Introduction to ION Motion
- ION Wheel Basics
- ION Compliant Wheel Guide
- Onshape Application Examples
Product Options
| SKU | PRODUCT NAME | CAD & DRAWINGS |
| REV-21-2029-PK4 | 2in - 1/2in Hex - Soft - Compliant Wheel - 4 Pack | STEP FILE ONSHAPE DRAWING |
| REV-21-2030-PK4 | 2in - 1/2in Hex - Medium - Compliant Wheel - 4 Pack | STEP FILE ONSHAPE DRAWING |
| REV-21-2031-PK4 | 2in - 1/2in Hex - Hard - Compliant Wheel - 4 Pack | STEP FILE ONSHAPE DRAWING |
| REV-21-6555 | Compliant Wheel - 2in - MAXSpline - Medium - 10 Pack | STEP FILE ONSHAPE DRAWING |
| REV-21-2456 | 3in - MAXSpline - Medium - Compliant Wheel | STEP FILE ONSHAPE DRAWING |
| REV-21-2457 | 4in - MAXSpline - Medium - Compliant Wheel | STEP FILE ONSHAPE DRAWING |
